| Case Material................................... |
Extreme duty NEMA 4, IP66 watertight aluminum housing |
| Approx. Weight................................. |
1.4 lbs. / 634 grams (including battery pack) |
| Dimensions....................................... |
8.0 x 3.0 x 2.0, (approx. 203 mm x 76 mm x 51 mm) |
| Operating Temperature.................... |
-22ºF to +140ºF (-30ºC to +60ºC); Consult factory for temperature requirements beyond those listed. |
| Switch Options................................. |
4, 8, or 12 push-buttons; single- or dual-pressure |
| Switch Type..................................... |
Sealed silicon elastomer keypad, dust, water, oil, acid resistant with ‘tactile feel’, clear epoxy coated push buttons |
| Battery Life (continuous operation)... |
3 Volt alkaline battery pack or rechargeable Ni-Cad Battery pack. In U.S., Canada and non EC Countries, battery life is: Ni-Cad pack - 65 hours, Alkaline pack - 150 hours. In EC Countries, battery life is: Ni-Cad pack - 40 hours, Alkaline pack - 95 hours. |
| Transmit Indicator............................ |
Green LED flashes with every transmission |
| Low-Battery Indication...................... |
Yellow LED flashes for low battery; low battery alert signal beeps every 10 seconds |
| Battery Charging.............................. |
Internal or External Ni-Cad (External Ni-Cad availability pending). 10 hour charger standard, 1 hour charger optional. |
| Audio Speaker.................................. |
For key click, diagnostics and low battery indication |
| System Configuration....................... |
Saved in removable contact-less RFID key (Trans-Key™); defines system address, RF channel, key mapping and operation parameters |
| Antenna........................................... |
Internal |
| Transmitter Frequency...................... |
Unlicensed 903-927 MHz band for North and South America; other frequency bands are available for Europe and Asia |
| Approvals......................................... |
Worldwide standards safety acceptance, Class 3 (EN-954-1) for Stop Commands, SIL 3 (EN-61508) for structural design, US FCC and Industry Canada non-licensed operation |
| Operating Range.............................. |
In excess of 300 ft.(92 m) line of sight |
| Labels.............................................. |
Sheet of self-adhesive Mylar, reverse-printed labels supplied. Optional reverse engraved custom faceplate available. |
| Carrying Straps................................. |
Belt loop strap standard; shoulder strap optional |
